Cactus Materials, Inc

LIMITLESS POSSIBILITIES
Innovative Leader in Semiconductors and Silicon Photonics
Disruptor in Nano-Materials for Energy & Water

Cactus Materials, Inc. is an innovative company that develops disruptive products, designs state-of-the-art engineering solutions, and manufactures in high volume for its partners and customers worldwide.

Cactus for Innovation

and many more..

Applications


Semiconductor


Medical


High Power Electronics


Automotive

Semiconductors and Silicon Photonics
Wafer Bonding | LTCC/RF/Ceramic Packaging | Flex Electronics

Process Capability: up-to 8 inch wafers (see below process capability)

Room Temperature Wafer Bonding
and 3D Integration

  • Cactus developed proprietary low temperature wafer bonding techniques application for various materials: Oxide Bonding (CZ and FZ Wafers), LiTaO3-Si,  III-V to Si Wafer bonding, Multi-stack wafer alignment and bonding, and 3D integration through TSV process.
  • Radiation Hardened Avalanche Photo-detector  with in-house manufacturing. ​
  • Products: Thick Silicon on Insulator (SOI) MEMS Wafers, Si-Si bonded wafers, Si-III/V Materials bonded wafers: ​Contact Cactus Engineers

Flextronics, Sensors, and Roll-to-Roll Manufacturing
Medical | Display | HEV | Power Electronics

  • Cactus Materials provides design service and low volume production of end-to-end solution on flextronics applications (i.e. OLED, Thin film Battery, BioMed Devices).
  • Development of a transferable and roll to roll manufacturing including raw materials (thin stainless steel SUS/PET/PEN substrate) using Cactus proprietary process.
  • Cactus is co-located with world class manufacturing facility at ASU Research park Flexible Electronics and Display Center (FEDC). Contact Cactus Engineering Team.

 Thin Film Growth (CVD/PVD/ALD) and Characterization (TEM/SEM)

  • Cactus Materials has extensive experience in thin film growth and characterization.
  • Cactus has direct access to Aberration Corrected Transmission Electron Microscopy (TEM) at ASU (Nion, Titan) and Scanning Electron Microscopy (SEM), EELS, and HADFM.
  • Cactus Engineering team conducts research on thin film and TEM.
@courtesy ASU FEDC
Roll to roll thin (30 um to 100 um) substrates (SUS316L, SUS444, SUS304)

LTCC for mmWave 5G Antenna and High Reliability Packaging
5G I RF | Automotive | Power Electronics

  • Cactus Materials has the design capability of advanced ceramic LTCC materials (Cu/Au)
  • Multi-layer (40+) design and packaging.
  • Cactus partnered with one of the largest manufacturing facility in the world in Japan for high volume production.
  • All products are ISO & RoHS certified.
  • Cactus Customer includes fortune 500 companies

Cryogenic Electronics Measurement and Quantum Computing

Cactus provides measurement service for Cryogenic Electronics and Quantum Computing
  • DC / IV / low voltage measurements down to 10K and 4.2K (for research below 100 mK)
  • High frequency S-parameters measurements up to Wband (110 GHz)
  • Noise measurement up to 20GHz
  • Optical / fiber optic measurements
  • Other special measurement: Please contact Cactus Engineers

Advanced Ceramics
Advanced ceramic heater | Components | Solid State Battery Ceramic Materials

Ultra-Ceramic Thermal Heaters
The highest power density in the world

Cactus Ultra-Ceramic heaters for semiconductor, automotive, and medical applications.
  • Ramp up rate of custom designed heaters up to 1000°C/s.
  • Multi-layer (20+) lamination capability integrating RTD and heating elements (W, Mo)
  • Cactus especially designed a low voltage heater for Medical Industry
Multi-layers heater and RTD Sensors with PIN connectivity

Ceramic Materials and Components

 Cactus to develop the highest quality and unique custom designed ceramic components with various materials of choice (SiC, SiN, B4C, AlN, Alumina and zero expansion ceramic materials)​
​

2D and Nano-Materials for Energy and Water
Nanomaterials | Next Generation ceramic Solid State Battery

  • Products:
    • Patent pending antimicrobial nanomaterials for various applications funded by NASA grant.
    • Patent pending Ceraphene(TM), a Chemical Vapor Deposition (CVD) 2D graphene and Ceramic stacks of layers, for various applications.
    • Cactus is developing next generation materials for energy and water in collaboration with university, national labs, and partners. ​

WHY CHOOSE CACTUS MATERIALS?

THE DETAILS ARE IN THE DESIGN

Cactus Materials understands that no two engineering problems are the same.
​With our expertise in the field of ceramics, we can custom design and manufacture our products to better suit customers' needs and specifications.

Cactus News

  • Cactus Materials, Inc. become an Industrial Partner with NEWT (Nano-enabled Water Treatment)- A NSF funded Nanosystems Engineering Research Center: http://www.newtcenter.org/#!domestic--international-partners/cvok where Cactus Materials, Inc. collaborated for research with NEWT scientist on sensors and nanotechnology used in Energy and Water.
  • Department of Energy selected Cactus Materials, Inc. for a competitive Grant $200K to develop next generation engineered substrates for Low Gain Avalanche Photo detector (LGAD) and road-map for $1M additional funding.
  • Cactus is awarded NSF/NASA I-Corp Grant for Cactus Technology of Super-compact submillimeter-Wave Array Chip.
  • Cactus is awarded competitive NASA Grant to develop Wafer level packaging of multi-pixel receiver and transceiver array at mm and sub-mm wave frequency.
  • Cactus is selected for Top "Tech-Connect National Innovation Award": A wearable IoT multi-sensors bio-processor platform based on a novel electrode and predictive data management systems
  • Cactus is selected one of the 25 companies in Energy for Early Stage "Thin Film Solid State Battery" by NASA itech (A joint effort by NASA and Department of Energy (DOE)'s Advanced Research Projects Agency-Energy (ARPA-E).
Cactus Corporate News: ​
  • Cactus currently has 2 Sales Openings: Experienced Sales Manager positions having >5M+/yr sales under his/her belt. Primarily looking for salespeople with experience in Wafer Bonding, High Precision Cleaning solutions, Advanced Packaging equipment and solutions, Advanced thermal heaters - please contact Cactus at cactus@cactusmaterials.com if interested. ​​

    How can we help you?

Submit
Cactus Materials, Inc.
7700 S. River Parkway
Tempe, AZ 85284
sales@cactusmaterials.com


Global Partnership with
- Arizona State University (ASU), University of Washington (UW), University of Massachusetts Amherst (UoMA), and Many more..
- Asia Joint Co Ltd - Japan,
- Kaston Co Ltd- Taiwan and
- NTK, Japan.. many more.....
​- National Labs..
